Galvanized Roof Vent – Mill Finish GRV620 and GRV624
The GRV is a heavy duty galvanized Roof Vent hood.
PRODUCT FEATURES
- Riveted construction, no caulk
- Draw-formed base
PRODUCT SPECIFICATIONS
- 26 gauge mill finish galvanized steel
- Flapper
RECOMMENDATION
Recommended for 4/12 roof pitch and steeper. Not recommended for flat roofs.
| Model | Flapper | Screen | Each # | Qty | Case # | Package | UPC | Labeled | Dia. | Tail |
|---|---|---|---|---|---|---|---|---|---|---|
| GRV620 | flapper | n/a | 12120 | 1 | 012120 | Ind. Box | 722048121201 | • | 4" | flush |
| GRV620 | flapper | n/a | 12120 | 160 | 712120 | Skid | 722048121201 | • | 4" | flush |
| GRV620 | flapper | n/a | 12121 | 1 | 012121 | Ind. Box | 722048121218 | • | 4" | with collar |
| GRV620 | flapper | n/a | 12121 | 120 | 712121 | Skid | 722048121218 | • | 4" | with collar |
| GRV624 | flapper | ¼"x¼" removable | 11755 | 1 | 011755 | Ind. Box | 722048117556 | • | 4" | flush |
| GRV624 | flapper | ¼"x¼" removable | 11755 | 160 | 711755 | Skid | 722048117556 | • | 4" | flush |
| GRV624 | flapper | ¼"x¼" removable | 11756 | 1 | 11756 | Ind. Box | 722048117563 | • | 4" | with collar |
| GRV624 | flapper | ¼"x¼" removable | 11756 | 120 | 711756 | Skid | 722048117563 | • | 4" | with collar |
| GRV624 | flapper | ¼"x¼" removable | 11793 | 1 | 011793 | Ind. Box | 722048117938 | • | 6" | flush |
| GRV624 | flapper | ¼"x¼" removable | 11793 | 60 | 711796 | Skid | 722048117938 | • | 6" | flush |
| GRV624 | flapper | ¼"x¼" removable | 11794 | 1 | 011794 | Ind. Box | 722048117945 | • | 6" | with collar |
| GRV624 | flapper | ¼"x¼" removable | 11794 | 60 | 711794 | Skid | 722048117945 | • | 6" | with collar |
| GRV624 | flapper | ¼"x¼" removable | 11772 | 1 | 011772 | Ind. Box | 722048117723 | • | 6"-8" (3¼"x10") | flush |
| GRV624 | flapper | ¼"x¼" removable | 11773 | 54 | 711772 | Skid | 722048117723 | • | 6"-8" (3¼"x10") | flush |
| GRV624 | flapper | ¼"x¼" removable | 11773 | 1 | 011773 | Ind. Box | 722048117730 | • | 7" | flush |
| GRV624 | flapper | ¼"x¼" removable | 11868 | 1 | 011868 | Ind. Box | 722048118683 | • | 7" | with collar |
| GRV624 | flapper | ¼"x¼" removable | 11868 | 60 | 711868 | Skid | 722048118683 | • | 7" | with collar |
| GRV624 | flapper | ¼"x¼" removable | 11774 | 1 | 011774 | Ind. Box | 722048117747 | • | 10" | flush |
